IPv4 Multicast Addressing and Ethernet MAC Mapping

In the previous article, we built a high-level map of multicast: sources send traffic to a logical group, receivers express interest, and the network replicates packets only where downstream paths branch.

This article moves one level deeper and focuses on two closely related questions:

1. How is the IPv4 multicast address space organized?
2. How does an IPv4 multicast group become an Ethernet multicast MAC address?

These two topics belong together because multicast traffic is identified by an IP group at Layer 3, but an Ethernet switch still needs a destination MAC address at Layer 2.

By the end of this article, you should be able to:

• Recognize the main IPv4 multicast address blocks;
• Distinguish Group G from an SSM Channel (S,G);
• Explain the difference between address scope, TTL, and administrative boundaries;
• Calculate the Ethernet multicast MAC for any IPv4 multicast group;
• Explain why 32 different IPv4 groups can map to the same MAC;
• Identify the planning risks created by multicast MAC overlap.

1. The Nature of an IPv4 Multicast Address

1.1 A Multicast Address Is a Destination Address

An IPv4 multicast address identifies a logical receiver group. It can therefore appear only in the destination-address field of an IPv4 packet.

A valid multicast packet looks like this:

Source IP:      192.168.10.10
Destination IP: 239.1.1.1

The source address identifies the sender, while the destination address identifies the multicast group.

A multicast address cannot be used as an IPv4 source address:

Source IP:      239.1.1.1
Destination IP: 192.168.10.20

This is invalid because 239.1.1.1 represents a group, not a transmitting host.

A useful way to remember the distinction is:

Source Address = Who sent the traffic?
Group Address  = Which logical channel carries the traffic?

1.2 A Group Address Is Not an Interface Address

A unicast address is normally configured directly on an interface:

interface Ethernet0
 ip address 192.168.10.20 255.255.255.0

A multicast group is different. The group address is not assigned to an interface as the interface’s host address.

Instead, an application asks the operating system to join a group through a specific interface:

Application
    │
    │ Join 239.1.1.1 on ens3
    ▼
Operating System
    │
    ▼
Interface ens3

The distinction is important:

A multicast group address identifies a logical receiver group rather than a specific host or interface.

The host joins the group through an interface; it does not configure the group as the interface address.

1.3 Multicast Group and SSM Channel

In Any-Source Multicast, or ASM, a receiver normally identifies only the group:

G

For example:

239.1.1.1

This logical object is called a multicast group.

In Source-Specific Multicast, or SSM, a receiver identifies both the source and the group:

(S,G)

For example:

(10.1.1.10, 232.1.1.1)

This is called an SSM channel.

Two channels can use the same group and still be different because the sources are different:

(10.1.1.10, 232.1.1.1)
(10.1.1.20, 232.1.1.1)

For operational documentation, especially in market-data environments, the complete service identifier is often:

Source IP + Group IP + UDP Port

2. The IPv4 Multicast Address Space

IPv4 multicast uses:

224.0.0.0/4

The complete range is:

224.0.0.0 - 239.255.255.255

Traditional classful terminology called this the Class D address space. Modern documentation usually calls it the IPv4 multicast address space.

The four most significant bits are fixed:

1110

┌──────────┬────────────────────────────┐
│   1110   │       Remaining 28 bits    │
└──────────┴────────────────────────────┘
  4 bits             28 bits

The remaining 28 bits theoretically provide:

2^28 = 268,435,456

possible values.

However, the range is not one large pool from which applications can choose arbitrary addresses. IANA has divided it into blocks with different purposes and scopes.

3. The Most Important IPv4 Multicast Address Blocks

The following blocks are the most important for day-to-day network design.

Other ranges inside 224.0.0.0/4 are reserved or assigned for special purposes. They should not be used without checking the relevant IANA allocation.

4. Local Network Control Block: 224.0.0.0/24

The Local Network Control Block is:

224.0.0.0 - 224.0.0.255

Traffic sent to this block is not forwarded by routers off the local link.

Common addresses include:

These addresses belong to standard protocols and must not be reused by ordinary applications.

Link-Local Scope Is Not the Same as TTL 1

Many protocols using this block send packets with:

TTL = 1

However, the key rule is not that a device always forces the TTL to 1.

The correct distinction is:

• TTL limits how many Layer 3 hops a packet can traverse;
• The address semantics of 224.0.0.0/24 prevent routers from forwarding the traffic off the local link.

Even a malformed packet sent to 224.0.0.5 with a TTL of 10 is still not supposed to be routed onto another link.

When you see 224.0.0.X, think:

• Local-link protocol traffic;
• No cross-subnet forwarding;
• Local interface, VLAN, and control-plane troubleshooting;
• Not an address for normal application data.

5. Internetwork Control Block: 224.0.1.0/24

The Internetwork Control Block is:

224.0.1.0 - 224.0.1.255

Unlike 224.0.0.0/24, its address semantics do not restrict traffic to one local link.

A historical example is:

224.0.1.1

which was assigned to NTP multicast.

However, an address being eligible for routed use does not guarantee reachability.

Actual forwarding still depends on whether the network provides multicast service and applies the required forwarding and security policies.

The key principle is:

Address semantics define the intended scope; network configuration determines actual reachability.

6. Source-Specific Multicast Block: 232.0.0.0/8

The standard IPv4 SSM range is:

232.0.0.0 - 232.255.255.255

In SSM, a receiver identifies a specific source and group:

(S,G)

For example:

(10.10.10.10, 232.100.1.1)

When you see a group in 232/8, you should immediately think:

• Standard SSM address;
• Receiver identifies the source;
• The service is defined by (S,G);
• No rendezvous point is required for source discovery.

However, the address prefix alone does not:

• Create receiver membership;
• Build multicast forwarding state;
• Guarantee the shortest physical path;
• Reduce per-packet ASIC latency;
• Guarantee lossless delivery.

The address identifies the intended service model. The host and network must still be configured correctly.

This model is especially useful for known and fixed sources, such as financial market-data feeds:

Source IP:      10.10.10.10
Group IP:       232.100.1.1
UDP Port:       12001
Service Model:  SSM

7. GLOP and Documentation Space

7.1 GLOP

GLOP uses part of:

233.0.0.0/8

The historical allocation method maps a 16-bit ASN into a /24 block:

233.X.Y.0/24

For ASN 64500:

64500 / 256 = 251 remainder 244

so the corresponding block is:

233.251.244.0/24

GLOP is useful to understand historically, but it is not normally the first choice for modern internal enterprise multicast planning.

7.2 MCAST-TEST-NET

For documentation and example code, use:

233.252.0.0/24

For example:

Source IP:      192.0.2.10
Destination IP: 233.252.0.10

This avoids accidentally using a group assigned to a real protocol or production service.

8. Administratively Scoped Multicast: 239.0.0.0/8

The Administratively Scoped Multicast block is:

239.0.0.0 - 239.255.255.255

It is used for multicast services within an organization or administrative domain.

It is often compared with RFC 1918 private unicast space because both can be reused independently inside isolated networks.

However, they are different types of addresses:

RFC 1918 traffic is not globally routable as native public unicast. Private hosts normally access the public IPv4 Internet through NAT, a proxy, or another gateway mechanism.

Similarly, 239/8 traffic is not intended to be forwarded as native multicast beyond its administrative scope.

Both types of private traffic may still be carried as an inner packet inside a tunnel that crosses the public Internet.

The Address Does Not Enforce the Boundary

Using 239/8 does not automatically cause every edge router to discard the traffic.

The network must enforce the scope using mechanisms such as:

• Multicast boundaries;
• Group ACLs;
• VRFs;
• Firewall policies;
• Routing policies;
• Network segmentation.

A useful design principle is:

The address identifies administratively scoped multicast, but the network must enforce the actual scope boundary.

Important subranges include:

239.255.0.0/16

for IPv4 Local Scope, and:

239.192.0.0/14

for IPv4 Organization Local Scope.

An organization might create a plan such as:

239.192.10.0/24  Market Risk Data
239.192.20.0/24  Internal Monitoring
239.192.30.0/24  Backtesting Feeds

The address plan improves organization, but VRFs, ACLs, boundaries, and service ownership still provide the real isolation.

9. Scope, TTL, and Administrative Boundary

These three concepts are related but not interchangeable.

TTL

TTL answers:

How many more routed hops can this packet traverse?

TTL = 4

A Layer 2 switch does not decrease the IPv4 TTL during ordinary bridging.

Address Scope

Address scope answers:

What propagation range was this address block designed for?

For example, 224.0.0.0/24 is defined for local-link control traffic.

Administrative Boundary

An administrative boundary answers:

Where does the actual network stop forwarding this traffic?

For example, 239.192.0.0/14 is intended for internal organizational use, but an actual policy must enforce the boundary at the organization’s edge.

Do not use TTL as a replacement for a security boundary, and do not assume that selecting 239/8 eliminates the need for filtering.

10. Why an IPv4 Multicast Group Needs an Ethernet MAC

At Layer 3, multicast traffic uses an IPv4 group address.

At Layer 2, an Ethernet switch still forwards a frame according to its destination MAC address.

Therefore, a packet sent to:

239.1.1.1

must be encapsulated with an Ethernet multicast destination:

Destination IP:  239.1.1.1
Destination MAC: 01:00:5e:01:01:01

This MAC address is not the unicast MAC of any receiver and is not learned through ARP.

It is calculated directly from the multicast group.

11. Ethernet Multicast MAC Address Structure

The least significant bit of the first MAC octet is the Individual/Group bit:

0 = Individual address
1 = Group address

For example:

00:50:56:aa:bb:cc

is a unicast MAC because the I/G bit is 0.

By contrast:

01:00:5e:01:01:01

is a multicast MAC because the I/G bit is 1.

IPv4 multicast over Ethernet uses the fixed prefix:

01:00:5E

The complete mapped range is:

01:00:5E:00:00:00
-
01:00:5E:7F:FF:FF

The most significant bit of the fourth octet is fixed to 0:

01:00:5E:0xxxxxxx:xxxxxxxx:xxxxxxxx

Only the final 23 bits are therefore available for IPv4 group information.

12. IPv4-to-MAC Mapping Rule

An IPv4 multicast address has 28 variable group bits:

┌──────────┬────────────────────────────┐
│   1110   │       Group ID: 28 bits    │
└──────────┴────────────────────────────┘
  4 bits             28 bits

The Ethernet multicast MAC can retain only 23 of them.

The lower 23 bits of the IPv4 group are copied into the lower 23 bits of the MAC:

IPv4 Multicast Address:

┌──────────┬─────────────┬────────────────────────┐
│   1110   │ 5 bits lost │   Lowest 23 bits kept  │
└──────────┴─────────────┴────────────────────────┘
  4 bits       5 bits              23 bits


Ethernet Multicast MAC:

┌────────────────────────┬───┬────────────────────────┐
│       01:00:5E          │ 0 │   Lowest 23 IP bits    │
└────────────────────────┴───┴────────────────────────┘
         24 bits          1 bit         23 bits

If the group is:

A.B.C.D

the mapped MAC is:

01:00:5E:(B & 0x7F):C:D

The mapping keeps:

• The lower seven bits of the second IP octet;
• All eight bits of the third octet;
• All eight bits of the fourth octet.

It discards:

• The lower four bits of the first octet;
• The most significant bit of the second octet.

13. Mapping Examples

239.1.1.1

Second octet: 1
1 & 0x7F = 1

Convert 1.1.1 to hexadecimal:

01:01:01

Result:

239.1.1.1
→ 01:00:5E:01:01:01

232.100.1.10

100 & 0x7F = 100
100 = 0x64
1   = 0x01
10  = 0x0A

Result:

232.100.1.10
→ 01:00:5E:64:01:0A

239.192.10.20

The second octet is greater than 127, so subtract 128:

192 - 128 = 64

Convert to hexadecimal:

64 = 0x40
10 = 0x0A
20 = 0x14

Result:

239.192.10.20
→ 01:00:5E:40:0A:14

A quick mental method is:

1. Start with 01:00:5E;
2. Keep only the lower seven bits of the second IP octet;
3. Convert the final three values to hexadecimal.

14. Why 32 IPv4 Groups Can Map to One MAC

The IPv4 multicast group contains 28 variable bits, but the Ethernet mapping retains only 23:

28 - 23 = 5

Five discarded bits create:

2^5 = 32

possible IPv4 groups that map to the same Ethernet multicast MAC.

This is known as:

32:1 multicast MAC overlap

Two groups collide when their lower 23 bits are identical:

IP1 & 0x7FFFFF == IP2 & 0x7FFFFF

In dotted-decimal terms:

• The lower seven bits of the second octet must match;
• The third octet must match;
• The fourth octet must match.

Changes to the first octet do not affect the result.

For example, all of these map to:

01:00:5E:01:01:01

224.1.1.1
224.129.1.1
225.1.1.1
225.129.1.1
232.1.1.1
232.129.1.1
239.1.1.1
239.129.1.1

The full combination consists of:

16 possible first octets × 2 possible values of the discarded second-octet bit
= 32 groups

15. What MAC Overlap Actually Means

MAC overlap does not mean that the IPv4 groups become identical.

For example:

232.1.1.1
239.1.1.1

remain different Layer 3 groups even though both map to:

01:00:5E:01:01:01

Their destination IP addresses remain different, and applications can still distinguish them.

MAC overlap does not:

• Change the destination IP;
• Change the UDP port;
• Merge two channels;
• Modify the packet payload.

However, it may cause Layer 2 over-forwarding.

If a switch forwards multicast using only:

VLAN + Destination Multicast MAC

then different groups sharing one MAC may also share the same outgoing-port list.

Example:

Receiver A joins 232.1.1.1
Receiver B joins 239.1.1.1

Both map to:

01:00:5E:01:01:01

A MAC-based implementation may produce:

VLAN 10
01:00:5E:01:01:01
→ Port A, Port B

Traffic for either group may then reach both ports.

The receiving host can still inspect the destination IP and discard traffic for groups it did not join, but the unnecessary packets may consume:

• Link bandwidth;
• NIC resources;
• Receive queues;
• Kernel packet-processing capacity;
• Monitoring and capture resources.

This matters most in high-throughput or low-latency environments.

16. The Practical Impact Depends on the Switch

Not all platforms use the same multicast forwarding key.

Possible implementations include:

VLAN + Multicast MAC

VLAN + Group IP

or:

VLAN + Source IP + Group IP

Therefore, the same MAC overlap may cause over-forwarding on one platform but not on another.

The following command showing an IP group:

show ip igmp snooping groups

does not prove that the ASIC uses IP-based forwarding.

A CLI can display control-plane group information while the hardware forwarding table uses another key.

To determine actual behavior, verify:

• Device model;
• ASIC architecture;
• Software version;
• Vendor documentation;
• Hardware forwarding entries;
• Packet behavior on receiver-facing links.

The general principle is:

Multicast MAC overlap is inherent in the mapping process, but its forwarding impact depends on the switch implementation.

17. Address-Planning Principles

17.1 Compare the Complete Lower 23 Bits

When planning groups in the same VLAN or bridge domain, compare:

Second octet & 0x7F
Third octet
Fourth octet

If all three values match, the groups map to the same MAC.

17.2 Changing the First Octet Does Not Help

These addresses collide:

232.1.1.1
239.1.1.1

because the first IP octet does not participate in the mapping.

17.3 Second Octets That Differ by 128 Collide

These addresses also collide:

239.1.1.1
239.129.1.1

because:

1 & 0x7F   = 1
129 & 0x7F = 1

There is no universal planning rule based on a fixed increment. The correct rule is to compare the complete lower 23 bits.

17.4 A Simple Local Planning Method

One practical approach is to fix the first two octets and allocate unique values in the final two:

239.192.1.1
239.192.1.2
239.192.2.1
239.192.2.2

These map to:

01:00:5E:40:01:01
01:00:5E:40:01:02
01:00:5E:40:02:01
01:00:5E:40:02:02

17.5 Check Across SSM and Internal Ranges

The following groups belong to different multicast blocks:

232.100.1.1
239.100.1.1

but both map to:

01:00:5E:64:01:01

Do not perform SSM and internal ASM planning independently without a global overlap check.

17.6 Not Every Collision Must Be Eliminated Globally

A collision is most relevant when the groups share the same Layer 2 domain.

For example, identical mapped MAC addresses in different VLANs do not normally share the same forwarding entry because the VLAN is part of the lookup context.

Risk depends on:

• Whether groups share one VLAN or bridge domain;
• Platform forwarding behavior;
• Traffic volume;
• Receiver sensitivity;
• Hardware resource limits;
• Mixed-vendor designs;
• Low-latency requirements.

For high-bandwidth or low-latency networks, avoid unnecessary overlap within the same Layer 2 domain whenever practical.

18. A Small Multicast MAC Audit Tool

The following Python 3 tool accepts one or more IPv4 multicast groups and reports any MAC collisions.

#!/usr/bin/env python3

import ipaddress
import re
from collections import defaultdict


def multicast_ip_to_mac(group_ip):
    ip = ipaddress.IPv4Address(group_ip)

    if not ip.is_multicast:
        raise ValueError(
            "{} is not an IPv4 multicast address".format(group_ip)
        )

    low_23_bits = int(ip) & 0x7FFFFF
    mac_value = 0x01005E000000 | low_23_bits
    mac_hex = "{:012x}".format(mac_value)

    return ":".join(
        mac_hex[index:index + 2]
        for index in range(0, 12, 2)
    )


def collect_groups():
    groups = []

    print("IPv4 Multicast MAC Collision Audit")
    print("----------------------------------")
    print("Enter one or more multicast IP addresses.")
    print("Separate multiple addresses with spaces or commas.")
    print("Press Enter on an empty line to start the audit.\n")

    while True:
        try:
            user_input = input("Multicast IP: ").strip()
        except (EOFError, KeyboardInterrupt):
            print()
            break

        if not user_input:
            break

        for address in re.split(r"[\s,]+", user_input):
            if not address:
                continue

            try:
                ip = ipaddress.IPv4Address(address)
            except ipaddress.AddressValueError:
                print("  Skipped: invalid IPv4 address: {}".format(address))
                continue

            if not ip.is_multicast:
                print("  Skipped: not a multicast address: {}".format(address))
                continue

            normalized = str(ip)

            if normalized not in groups:
                groups.append(normalized)

    return groups


def print_report(groups):
    if not groups:
        print("\nNo valid multicast addresses were entered.")
        return

    mapping = defaultdict(list)

    print("\nMulticast IP to MAC Mapping")
    print("-" * 45)

    for group in groups:
        mac = multicast_ip_to_mac(group)
        mapping[mac].append(group)
        print("{:<18} {}".format(group, mac))

    collisions = {
        mac: addresses
        for mac, addresses in mapping.items()
        if len(addresses) > 1
    }

    if not collisions:
        print("\nAudit result: No multicast MAC collisions were found.")
        return

    print("\nAudit result: Multicast MAC collisions were found.")

    for mac, addresses in collisions.items():
        print("\n{}".format(mac))

        for address in addresses:
            print("  - {}".format(address))


if __name__ == "__main__":
    print_report(collect_groups())

The tool answers one specific question:

Which IPv4 multicast groups map to the same Ethernet MAC?

It does not prove that a real switch will over-forward the traffic. That still depends on VLAN placement, platform architecture, and forwarding behavior.

19. Key Takeaways

• IPv4 multicast uses 224.0.0.0/4.
• A multicast address can be a destination but not a source address.
• A group address identifies a logical receiver group, not an interface.
• 224.0.0.0/24 is limited to the local link.
• 232.0.0.0/8 is the standard IPv4 SSM range.
• 233.252.0.0/24 is intended for documentation and examples.
• 239.0.0.0/8 is administratively scoped multicast space.
• TTL, address scope, and administrative boundaries are different concepts.
• Ethernet multicast uses the fixed 01:00:5E prefix for IPv4 mapping.
• Only the lower 23 bits of the IPv4 group are preserved in the MAC.
• Five discarded bits create a 32-to-1 IPv4-group-to-MAC mapping ratio.
• MAC overlap does not make two Layer 3 groups identical.
• On some platforms, overlap may cause Layer 2 over-forwarding.
• Address plans should compare the complete lower 23 bits.
• High-throughput and low-latency environments should avoid unnecessary overlap in the same Layer 2 domain.
• Address planning should record at least the source, group, UDP port, scope, VLAN or VRF, service owner, and redundancy design.
